3013

SkyTrak® Telehandler

Key Specs

  • Maximum Lift Capacity: 2700 lb / 1224.70 kg
  • Maximum Lift Height: 13 ft 1 in. / 3.99 m
  • Maximum Reach: 7 ft 1 in. / 2.16 m
SEE ALL SPECS

Key Features

  • Work in Confined Environments: Ultra-compact and highly maneuverable design
  • Enhance Your Capabilities: Excellent reach into truck beds, trailers and over obstacles
  • Keep Your Surroundings Intact: Rear-wheel steering for less ground disturbance
SEE ALL FEATURES
Performance
Drawbar Pull2623 lb / 1189.77 kg
Maximum Lift Capacity2700 lb / 1224.70 kg
Maximum Lift Height13 ft 1 in. / 3.99 m
Maximum Reach7 ft 1 in. / 2.16 m
Outriggers or StabilizersNo
Speed - Maximum Lift10.9 sec.
Speed - Maximum Lower7.7 sec.
Speed - Maximum Telescope In4.5 sec.
Speed - Maximum Telescope Out7.5 sec.
Speed - Maximum Travel10.5 mph / 16.90 km/h

Dimensional Data
Ground Clearance10 in. / 0.25 m
Machine Height6 ft 7 in. / 2.01 m
Machine Length8 ft 9 in. / 2.67 m
Machine Width4 ft 7 in. / 1.4 m
Tire Size11 / 65 x 12 Pneumatic Ag Tread
Wheelbase5 ft 7 in. / 1.7 m

Power Source
Capacity - Fuel Tank14.5 gal. / 54.89 L
Engine Horsepower24.8 hp / 18.50 kW
Engine ManufacturerKubota
Engine ModelV-1505
Maximum Engine RPM2300 rpm

General
Axle-FrontHigh Bias, Limited Slip
Axle-RearOscillating
Function Pump TypeGear
Hydraulic System Pressure3988 psi / 279.28 Kg/cm2
Operating Vehicle Weight5280 lb / 2394.97 kg
Transmission - Nr Forward Gears Standard1
Transmission - Nr Reverse Gears1
Transmission TypeHydrostatic

  • Work in Confined Environments: Ultra-compact and highly maneuverable design
  • Enhance Your Capabilities: Excellent reach into truck beds, trailers and over obstacles
  • Keep Your Surroundings Intact: Rear-wheel steering for less ground disturbance
  • Easily Move from Job to Job: Low weight for easy transportation with pick-up and trailer
  • Boost Operator Comfort: Oscillating rear axle provides a smoother ride for the operator and load
  • Increase Versatility: Optional hydraulic universal skid steer coupler for use with skid steer attachments
  • JLG Standard Carriage
    Standard Carriage
  • JLG Pallet Forks
    Pallet Forks
  • JLG Material Bucket
    Material Buckets
